How We Saved a Failed VMware ESXi Server in 12 Hours: 8-Drive Dell SAS RAID Case Study

Published 25 April 2026. Updated 25 October 2026.

VMware ESXi Data Recovery: A Failed Dell Server from a Sydney MSP Lands at the Rhodes, NSW Lab

Jason runs a managed IT services company in Sydney. One of his customers had a Dell server running VMware ESXi fail with an error. Their existing IT support company tried to bring it back, couldn’t recover the missing snapshot, and couldn’t locate the data store at all. Several critical business folders sat trapped inside virtual machines that weren’t mounting any more. The 8 drives travelled to Payam Data Recovery’s lab in Rhodes, New South Wales, where owner Payam Toloo took the case on. This VMware ESXi data recovery case study walks through the SAS imaging challenge, the surprise clone failure on one professional tool that succeeded on another, the RAID rebuild from image files, and the VMFS-and-VMDK extraction inside 12 hours. If you’re looking for the matching service, see our RAID and server data recovery service.



The Problem: 8 SAS Drives, a Failed ESXi Host, and a Lost Data Store

The drives in front of us were 8 × Dell ST300MM008 SAS 300GB enterprise hard drives. SAS (Serial Attached SCSI) is the interface enterprise servers use for the data and boot drives that have to deliver consistent performance under sustained load. Visually, SAS drives look almost identical to consumer SATA drives, but the connector is different: SATA has a small gap between the data and power sections of the connector, SAS has no gap. That difference matters because consumer hardware imagers built for SATA can’t read SAS drives at all, even when the drive is physically plugged in. VMware ESXi data recovery from an enterprise Dell server depends on having SAS-compatible imaging hardware before any other step is possible.

The starting plan was the standard one. Connect the drives one at a time to Atola Insight Forensic with its optional SAS add-on, confirm detection, check SMART, run a media scan to verify every sector is readable, then sector-clone each drive onto stable media so all subsequent recovery work happens on copies. All 8 drives detected. SMART status was clean across the set. Media scans showed every sector readable. So far, this was looking like a straightforward VMware ESXi data recovery job.

Then the first clone attempt fell apart. Within minutes of starting the sector-by-sector copy on the Atola, every sector started returning unreadable. Not a few weak sectors at the end of the drive, not a slow patch in one zone, but the entire drive going opaque to the cloning process. The drive sounded perfectly healthy on the bench. SMART status was still clean. The diagnostic data and the cloning behaviour were saying contradictory things.

A second attempt with the same drive on the same tool produced the same result. Every sector unreadable. There’s no obvious explanation in the data for why a drive that detects clean, scans clean, and sounds healthy would refuse to clone, but VMware ESXi data recovery on enterprise SAS hardware is full of edge cases like this and it’s the reason the lab keeps multiple imaging platforms on hand.

The VMware ESXi Data Recovery Process

Step one of the VMware ESXi data recovery had to pivot. The Atola wasn’t going to image these drives. The lab switched to PC-3000 SAS, the SAS and SCSI variant of the PC-3000 platform. PC-3000 SAS is purpose-built for enterprise SAS drive recovery and uses a different read-strategy stack than the Atola. It’s also expensive and rarely needed, which is why most labs don’t have it.

The first drive cloned cleanly on PC-3000 SAS in approximately 45 minutes. Image file written to a 4TB target drive. The second drive, same. Each drive in the 8-drive set imaged successfully on PC-3000 SAS at the same pace. Why did one tool fail and the other succeed on the same hardware? There’s no definitive answer. Different imaging tools handle SAS vendor commands and read-error retry logic differently, and a drive that hits a corner case in one tool’s logic can be entirely cooperative with another. The reason the lab carries multiple platforms isn’t redundancy for its own sake, it’s because there’s no single tool that handles every drive.

Step two of the VMware ESXi data recovery was the RAID rebuild. All 8 image files were opened in UFS Explorer Professional Recovery. RAID rebuild software typically expects to work with physical drives, not image files, and most tools won’t auto-detect the array geometry from images. UFS Explorer is the exception: it scanned the 8 image files, identified the RAID parameters automatically, and rebuilt the storage volume.

Step three was reading what was inside. The rebuilt RAID exposed multiple volumes. The second volume showed a healthy VMFS file system, which is VMware’s proprietary file system for ESXi data stores. UFS Explorer can read VMFS directly, which is the second non-obvious capability the job depended on (Windows can’t read VMFS natively, and most general-purpose recovery tools can’t either). Inside the VMFS volume sat large VMDK virtual machine disk files: the actual virtual servers Jason’s customer had been running on the ESXi host.

The lab mounted one of the VMDK files to check the data inside. No corruption, no missing folder structure, no broken file system inside the virtual disk. Each VMDK was then copied off, file-by-file, to a fresh external drive. The critical business folders Jason needed for his customer were among the first content extracted, exactly as they’d been sitting on the live VMs before the host failure.

VMware ESXi Data Recovery Results

Total elapsed time from the moment the drives arrived at the lab in Rhodes, NSW to the moment Jason had a usable copy of the data: 12 hours. Every VMDK on the VMFS volume came off cleanly. Every critical business folder was present and verified. The VMware ESXi data recovery delivered exactly what an MSP customer needs from a case like this: not a probable recovery, not a partial recovery, but the actual virtual machine files in a form that can be remounted on a working ESXi host or read directly with VMware’s standard tools.

Total drives processed: 8. Total recovery turnaround: 12 hours. Cloning step alone: roughly 6 hours of imaging time across 8 drives plus the diagnostic work either side of it.

Why Professional VMware ESXi Data Recovery Matters

Four things make a case like this difficult, and most general-purpose IT shops and smaller data recovery operations will hit a wall at one of them.

First, SAS hardware. Reading enterprise SAS drives without the original RAID controller and without the original Dell server requires SAS-capable imaging hardware. The cheap option (a USB SAS dock) won’t deliver the read-error handling needed for an unstable drive, and the standard SATA imagers most recovery shops own are simply not compatible. VMware ESXi data recovery on a Dell server starts with owning SAS hardware that can read drives end of life.

Second, advanced cloning tools. Even with SAS-compatible hardware, an individual drive can refuse to clone on one tool and clone perfectly on another, exactly as happened here with the Atola-to-PC-3000-SAS pivot. A lab with only one SAS imager would have stopped at the first failed clone attempt. VMware ESXi data recovery on production hardware needs at least two professional-grade imaging platforms in the room.

Third, RAID rebuild from image files. Most RAID rebuild software won’t work with image files at all, only with physical drives. The few tools that do (UFS Explorer chief among them) are also the few that handle non-standard parity rotations, unusual stripe sizes, and the half-dozen Dell-specific PERC controller layouts that production servers actually run. Without a tool that handles image-file rebuilds, you have to rebuild on the original drives, which is risky if any of them is unstable.

Fourth, VMFS file system access. Once the RAID is rebuilt, the file system on top is VMFS, not NTFS or ext4. Windows can’t read VMFS natively. Linux can read it with effort but not in a recovery-friendly way. UFS Explorer reads VMFS directly and exposes the VMDK files inside. Without that capability, even a successful RAID rebuild leaves you staring at an opaque block device.

Each of those four steps is non-trivial on its own. Stacked together in a single VMware ESXi data recovery job, they explain why most managed IT services companies escalate this kind of failure rather than attempt it in-house.

For background on how VMware ESXi and VMFS work together, the Wikipedia article on VMware ESXi covers the hypervisor architecture and data store model. For more on the SAS interface and how it differs from SATA, the Wikipedia article on Serial Attached SCSI explains the protocol and connector differences that matter for VMware ESXi data recovery from enterprise hardware.
