Fire Water Damaged Hard Drive Recovery Case Study: Photography Studio 19TB Recovered

Published 4 March 2026. Updated 25 October 2026.

David, a photographer from Staff Australia, sent five hard drives to Payam Data Recovery after a devastating fire at his photography studio. The fire itself was not the main threat to his data. It was the water used by the fire brigade to extinguish it that caused more damage than the flames. Four Seagate 8TB drives containing years of client photos, plus one 24TB drive, all needed professional assessment. This fire and water damaged hard drive data recovery case study documents how Payam Data Recovery tested, diagnosed, cloned, and recovered all 19TB of David’s photography work.

David made one critical decision that likely saved his data: he did not plug the drives in after the fire. Powering on water-damaged drives can cause short circuits, corrosion damage, and permanent data loss. This fire and water damaged hard drive data recovery case study shows why that decision, combined with professional assessment, led to a complete recovery. Based in Australia, Payam Data Recovery handles fire and water damaged drive cases for customers across Australia and internationally, including from the USA, New Zealand, UK, and worldwide. The easiest way for an international customer to reach us is by email at help@payam.com.au, which works in every time zone.

The Problem: Photography Studio Fire and Water Damage

David’s photography studio suffered a fire, but the real danger to his hard drives came from the fire brigade’s water. Water can cause corrosion on a hard drive’s printed circuit board (PCB), contaminate the internal platters if it seeps inside the enclosure, and create short circuits if the drive is powered on while still damp.

Four Seagate 8TB drives held years of client photos. For a professional photographer, this data represents not just personal work but a legal and professional obligation to clients. David also sent a 24TB drive to use as the destination for recovered data.

David’s smart decision not to power on the drives after the fire was crucial. Many people instinctively plug drives in to check if they still work, but this is one of the worst things you can do after water exposure. The electrical components on the PCB can short-circuit, and any moisture inside the drive can cause the read/write heads to stick to the platters. This fire and water damaged hard drive data recovery case study began with a client who knew to send the drives straight to professionals.

Fire and Water Damaged Hard Drive Data Recovery Case Study: Diagnosis

The data recovery engineer inspected the drives carefully. There were no obvious signs of burning or physical damage, just residue from the smoke. However, when he checked the printed circuit board (PCB) by smell, he detected a strong burnt odour, indicating potential electrical damage from the fire or water exposure.

Despite this concerning finding, the data recovery engineer tested each drive using the Atola Insight Forensic tool. All four drives powered up, spun normally, and produced no unusual noises. SMART status passed on all drives. Media tests passed on all drives. Despite surviving a fire and water damage, all four drives appeared healthy.

The data recovery engineer initially expected a RAID array, which is typical for photographers storing large volumes of data. He checked in Windows Device Manager and all drives were detected. Using WinHex, he noticed something unexpected: one drive was only 20% full while the others had different amounts of data. This did not fit a typical RAID configuration.

Using UFS Explorer, the data recovery engineer discovered the drives were not in a RAID array at all. Instead, they contained four separate Apple HFS partitions, each with different volume labels. David had organised his client photos by year, with one drive dedicated to 2023, one for 2024, one for 2025, and another for additional work. Random file checks confirmed everything was intact and accessible.

The Fire and Water Damaged Hard Drive Data Recovery Case Study Process

Even though all four drives appeared healthy, the data recovery engineer cloned each drive as a safety measure. This is standard practice in professional hard drive data recovery. Cloning creates an exact sector-by-sector copy of each drive, protecting the data in case a drive deteriorates later. Drives that have been exposed to water can develop problems days or weeks after the initial damage as corrosion progresses.

After cloning, the data recovery engineer saved all the recovered data, totalling 19TB, to David’s 24TB drive. This fire and water damaged hard drive data recovery case study qualified as Payam Data Recovery’s basic backup service, an affordable option for situations where the drives are functional but need professional hands to safely extract and preserve the data.

Fire and Water Damaged Hard Drive Data Recovery Case Study Results

All 19TB of David’s client photos were recovered in full. Every year of work, across all four drives, was intact and accessible. The random file checks performed during diagnosis confirmed that none of the photos were corrupted.

This fire and water damaged hard drive data recovery case study had a straightforward outcome because David made the right decision from the start: he did not plug the drives in after the fire, and he sent them straight to a professional data recovery company. In many fire and water damage cases, the drives themselves survive, but the owner causes further damage by powering them on before they have been properly assessed.

Why Professional Assessment After Fire or Water Damage Matters

This fire and water damaged hard drive data recovery case study highlights why professional assessment is essential after any disaster involving hard drives:

Invisible damage can be present. David’s drives showed no visible burns or physical damage, but the PCB had a strong burnt smell. Without professional testing, this electrical damage could have caused problems. The Atola Insight Forensic tool confirmed the drives were safe to power on before any data was accessed.

Water damage gets worse over time. Corrosion from water exposure can progress over days and weeks. Drives that appear healthy immediately after water damage can deteriorate rapidly. Cloning the drives immediately, as the data recovery engineer did in this case, protects the data before corrosion has time to cause further problems.

RAID assumptions can be dangerous. The data recovery engineer initially expected a RAID array, which would have required a completely different recovery approach. If someone had attempted to rebuild a non-existent RAID, the individual drive data could have been destroyed. Professional diagnosis identified the true structure: four separate Apple HFS partitions organised by year.

Do not power on water-damaged drives. David’s decision not to plug in his drives after the fire was the single most important factor in this successful recovery. Powering on drives with moisture or electrical damage can cause short circuits, head crashes, and permanent data loss.

Professional hard drive data recovery at Payam Data Recovery uses the Ace Lab PC-3000, DeepSpar Disk Imagers, Atola Insight Forensic, and an ISO 5 certified laminar flow cabinet for drives requiring mechanical work. Over 2,000 IT companies and computer repair businesses across Australia trust Payam with their most difficult cases.

What to Do If Your Hard Drives Are Damaged by Fire or Water

Based on this fire and water damaged hard drive data recovery case study, here is what to do if your drives have been exposed to fire, water, or any other disaster:

• Do not plug the drives in. This is the most important step. Powering on wet or smoke-damaged drives can cause short circuits and permanent data loss
• Do not attempt to dry the drives using heat, hairdryers, or rice. These methods can cause further damage
• Do not open the drives. Hard drives contain precision components that must only be handled in a laminar flow cabinet
• Keep the drives in their current state and send them to a professional data recovery company as soon as possible
• If the drives were submerged in water, keep them in a sealed plastic bag to prevent the moisture from evaporating and leaving mineral deposits on the platters

Why People Choose Payam Data Recovery

A failed hard drive needs an experienced data recovery engineer, and often a matching donor part. We work on 10 to 15 drives with failed heads every day.

• We are a specialist data recovery lab, not a computer repair shop. We have been recovering data since 1998, from over 300,000 devices.
• The best equipped data recovery lab in Australia: an ISO 5 certified laminar flow cabinet for head replacements, an anti-static lab, microscopes and microsoldering stations for circuit board work, the Ace Lab PC-3000, Atola Insight Forensic and DeepSpar Disk Imager, and over 30,000 donor parts, including around 20,000 donor hard drives. When your drive needs a matching part, it is usually already on our shelf.
• Over 2,000 IT companies and computer shops across Australia send us their customers’ complex cases, and data recovery labs and IT companies in more than 50 countries have sent us their difficult cases over the past ten years.
• Rated 4.9 from over 2,400 Google reviews.
• About 90% of our jobs are no fix, no fee. The hardest 10% carry an attempt fee.
• See your files before you pay. You tell us which files matter most. Before you pay for the recovery, we’ll send you a list of your recovered files so you can check them. If any of the files you listed are missing, tell us and we’ll search again.
• Pay by Visa, Mastercard, American Express, Apple Pay, Google Pay, Link or PayPal, split the cost with Afterpay, Zip, Klarna or PayPal Pay in 4, or pay by bank deposit (EFT).
• Everything is done in our own labs in Australia and never outsourced overseas. Call or visit us, and you can speak with the data recovery engineers who do the work.

We are not the cheapest. We are the best in Australia at this work. We know what to do, how to do it, and we will do our very best for you. Your best chance of getting your data back is with us.

Hard Drive Data Recovery Assessment

If you are facing a situation similar to this fire and water damaged hard drive data recovery case study, hard drive data recovery at Payam Data Recovery starts with a free assessment and quote with no obligation. Whether you have individual drives or a RAID array damaged by fire or water, we can help. For urgent situations such as business data loss after a disaster, we also offer a $150 urgent assessment that gives you a written quote within 1 to 2 hours.

For most faults the price is the same whatever the size of the drive, and current prices are on our hard drive data recovery page. Priority and Emergency are faster and cost more, and damaged heads on drives over 6TB are quoted individually. You receive a detailed quote before any work begins, so you know the exact cost upfront with no surprises.

Three service tiers are available:

• Economy: Best value, standard turnaround
• Priority: Faster turnaround, moves ahead of the Economy queue
• Emergency: Fastest possible, after-hours and weekends if needed

Payam Data Recovery recovers data from all hard drive brands including Seagate, Western Digital, Toshiba, Samsung, Hitachi, LaCie, and all others. All fault types are supported including fire damage, water damage, clicking drives, dropped drives, bad sectors, and drives not detected.

All prices include GST. If we recover your data and you pay, return delivery is free, including to New Zealand. Payam Data Recovery serves customers across Australia with laboratories in Sydney, Melbourne, and Brisbane, plus secure drop-off offices in Perth and Adelaide, which send your device to our lab in Rhodes, NSW at no cost. We also welcome international customers from the USA, New Zealand, UK, and worldwide. If anyone can recover your data, it’s us.

Frequently Asked Questions: Fire and Water Damaged Hard Drive Recovery

About Payam Data Recovery

Payam Data Recovery is an Australian data recovery company founded in 1998 with over 300,000 devices recovered. The company is trusted by over 2,000 IT professionals and computer repair businesses across Australia who send their most difficult cases, including fire and water damage recoveries like this fire and water damaged hard drive data recovery case study.

With full-service laboratories in Sydney (including our head office in Sydney CBD and our main data recovery lab in Rhodes, NSW), Melbourne, and Brisbane, plus secure drop-off offices in Perth and Adelaide, which send your device to our lab in Rhodes, NSW at no cost, Payam Data Recovery serves customers across Australia and internationally. All recovery work is performed in Australia and is never outsourced overseas.

For hard drive recoveries, the team uses the Ace Lab PC-3000, DeepSpar Disk Imagers, Atola Insight Forensic imagers, and an ISO 5 certified laminar flow cabinet for drives requiring mechanical work. Everything is done here in Australia. We never outsource overseas.

Related Hard Drive Data Recovery Case Studies

• 16-Drive RAID Recovery Case Study
• How to Fix a Clicking Hard Drive Case Study
• Western Digital Hard Drive Data Recovery Case Study
• Seagate Personal Cloud NAS Recovery Case Study
• Dropped Seagate hard drive head replacement case study
• Seagate PCB replacement case study

Video Transcript: Fire and Water Damaged Hard Drive Data Recovery Case Study

Hey, it’s Mike at Payam Data Recovery with owner Payam Toloo. David from Staff Australia sent in five hard drives from his photography studio after a devastating fire. The fire brigade’s water caused more damage than the flames. Four Seagate 8TB drives containing years of client photos, plus one 24TB drive to save everything to. David wisely didn’t plug them in after the fire to avoid further damage.

Payam inspected the drives. No visible burns or damage, just smoke residue. But when he sniffed the PCB to check for electrical damage, he got a shock. An awfully strong burnt smell. He tested each drive on his Atola Insight Forensic tool. They powered up, spun normally, no unusual noises. SMART status passed. Media tests passed. All four drives appeared healthy despite the fire.

Payam expected a RAID array, which is typical for photographers. He checked in Windows Device Manager, all detected. Using WinHex, he noticed one drive was only 20% full while the others had different amounts of data. He thought maybe RAID 5 with a hot spare, but UFS Explorer revealed something different. Four separate Apple HFS partitions, each with different volume labels. Not a RAID array at all. David had organised client photos by year. One drive for 2023, one for 2024, one for 2025. Random file checks confirmed everything worked perfectly.

Payam cloned each drive for safety and saved all 19TB to David’s 24TB drive. This qualified as Payam’s basic backup service, an affordable option for people who want professional hands handling their data safely.

This case study shows why Payam offers free assessments. They can test and fix nearly any problem. If you have data loss from fire, water, or any disaster, stop using the drives immediately and send them to Payam Data Recovery first before causing further damage. They’ll get your data back fast and keep costs as low as possible.
